TACLANE-Nano (KG-175N) Encryptor

Smallest, Lightest HAIPE® For Classified Mobile Applications

Extremely compact and mobile, the new TACLANE-Nano provides end-to-end HAIPE encryption in the smallest, lightest and lowest power configuration of any HAIPE device available today. The TACLANE-Nano is designed with the latest in crypto modernization technology to provide high assurance protection of voice, video and data classified TS/SCI and below at 50 Mb/s throughput and is MIL-STD-810G ruggedized to withstand the rigors of any mobile environment including tactical, mobile applications such as:

The TACLANE-Nano Inline Network Encryptor (INE) was submitted to NSA for certification in the 4th Quarter of 2018. The TACLANE-Nano can now be purchased via NSA IDIQ or GD Direct.


WHAT'S NEW

TACLANE ® Render Useless Zeroize (RUZ) Feature for Unattended Operation and High Risk Deployments Whitepaper

REQUEST WHITEPAPER NOW

Explore our whitepapers to get a thorough grounding in military-grade encryption and secure mobile communication solutions at the tactical edge.

Securing Your Mobile Mission

The TACLANE-Nano Inline Network Encryptor (INE) supports the bandwidth needed for voice, video and data applications (such as real time video and data analytics) in mobile environments including:


Taclane Nano Applications


Our Secure Deployable Communication Kit Partners

To bring operators a complete, turn-key solution for classified communications on-the-move, General Dynamics has partnered with several leading man portable deployable communication systems, baseband and SATCOM providers.


TACLANE and GEM are trademarks of General Dynamics. HAIPE is a registered trademark of the National Security Agency. All other product and service names are the property of their respective owners.

Features

The TACLANE-Nano will support optional software such as VLAN and TCP Performance Enhancing Proxy (PEP). Remote management and configuration is supported via the GEM® One Encryptor Manager to simplify operation and enable centralized secure management of all of your TACLANE devices on the network.

Key Features

  • Designed to protect information classified TS/SCI and Below

  • Simultaneous HAIPE v4.2.5 and IPMEIR 1.0 compliant

  • Simultaneous Suite A/B without user intervention

  • 50 Mb/s Throughput (100 Mb/s Aggregate) Greater throughput achievable dependent upon traffic mix

  • Small size (1.2”H x 3.5”W x 2.25”D)

  • Low power (5 Watts typical)

  • Hot swappable/redundant power from USB or Power over Ethernet (POE)

  • Embedded Agile TCP Performance Enhancing Proxy (PEP) for disadvantaged networks

  • Remote Zeroization Control Interface for Unattended Operations

  • Supports Agile VLAN feature for Layer 2/Layer 3 agility and advanced networking

  • Safe keying features including Classified/Unclassified Device Generated Shared Key (DGSK) and Exclusion Keys (EKs)

  • ACC and KMI OTNK compliant

  • IPv4/6 Dual Stack

  • MIL-STD-810G ruggedized / MIL-STD-461F EMI compliant

  • Supported by GEM One Remote Encryptor Manager

Optional Feature Enhancements:

Agile Virtual Local Area Network (VLAN): Adds Layer 2 VLAN tagged/ Non-IP Ethernet capability to the TACLANE encryptor enabling simultaneous HAIPE and Layer 2 traffic on a per packet basis without any infrastructure changes. TACLANE encryptors enabled with VLAN still interoperate with standard HAIPE encryptors. Other benefits include: equipment and cost savings, increased bandwidth efficiency, failover and redundancy.

TACLANE and GEM are trademarks of General Dynamics. HAIPE is a registered trademark of the National Security Agency. All other product and service names are the property of their respective owners.

Technical Specifications

View Datasheet

Size 1.2”H x 3.5”W x 2.25”D
19” Rack mountable, 4 Across, 1U
Weight: <8 Oz
Power
5 Watts (Typical)
Battery: Coin-Cell Battery (CR2450HR)
MIL-STD 461F compliant USB power supply
Performance 50 Mb/s throughput (100 Mb/s aggregate)
Greater throughput is achievable dependent upon
packet size
Reliability
229,000 Hrs Mean Time Between Failure (MTBF)
Environment
MIL-STD-810G compliant
Operating Temp: -40° to +60°C
Storage Temp: -40°C to +85°C
Humidity: 95% RH, Non-condensing
Operational Altitude: 1,500 ft below sea level to 50,000 ft above sea level
Storage/transit Altitude: 1,500 ft below sea level to 70,000 ft above sea level
Shock/Vibration: 40g shock, 11ms Transportation Vibration, General Vibration, Category 4
Sand: 40 mph winds
Dust: 20 mph winds
Rain: Drip, Flow Rate 280 liters/meter2/hour
Drop Test: 48” High Drop
EMI / TEMPEST: In accordance with NSTISSAM TEMPEST/1-92 Level 1
Standards Compliance
HAIPE v4.2.5
Crypto Modernization compliant
IPMEIR v1.0
Advanced Cryptographic Capability (ACC)
KMI Over The Network Keying (OTNK)
Foreign Interoperability  Algorithm Agile – Simultaneous Suite A/B/AES
EFF/IPMEIR without manual intervention
P3, S2, Q2
Power Options
Supports three hot-swappable power options including front/rear panel USB-C connectors and Ciphertext RJ45 Power Over Ethernet (PoE)
Warranty
3 year hardware and software warranty
Keying
Supports KMI OTNK, ACC, Exclusion Key, HAIPE to HAIPE Keying, APPK/PPK, FIREFLY, Enhanced
FIREFLY, Internet Key Exchange (IKE) v1/v2, Classified/Unclassified Device Generated Shared Key (DGSK)
Networking Features & Protocols

Protocols Supported: TCP, UDP, IPv4/IPv6 Dual Stack, ICMP, IGMP, ARP, DHCP, MLD, TFTP, HTTPS, HTTP, RIP, RIPv2, RIPng, NDP, IKE, IKEv2, HAIPE, IPMEIR, OTNK, CMS, XML, non IP with VLAN, TCP PEP

Networking Features: Dynamic IP addressing, dynamic key management (key distribution through H-to-H key transfer  and KMI enabled, red address confidentiality and selectable dynamic discovery via Generic Discovery/Secure Dynamic  Discovery or IMPEPD, dynamic routing updates through RIP and discovery protocols, support for route of last resort, support for VLAN and layer 2 traffic

Management: Full SNMPv3 management and HTTP browser based management, GEM One Manager

Multicast: IGMP and MLD on Red and Black networks

Quality of Service: Type of Service Octet bypass, PCP to TOS mapping for VLAN traffic, ECN congestion control bypass

Fragmentation: Support for fragmentation and reassembly on Black network traffic and fragmentation of Red IP traffic

Network Interfaces

Plaintext Data Interface: Electrical / Mechanical - IEEE 802.3/Ethernet2; copper RJ-45 10/100 Base-T

Ciphertext Data Interface: Electrical/Mechanical - IEEE 802.3/Ethernet2; copper RJ-45 10/100 Base-T

Console Management Interface: Electrical/Mechanical - USB 2.0; USB-C connector

Standard DS-101 key fill port; Micro USB connector

Remote zeroize input; Micro USB connector

Primary power 5VDC; USB Type-C connector

24/7 Customer Support

You are never alone when you partner with General Dynamics to secure your critical information. With the largest deployed base of NSA-certified encryptors worldwide, General Dynamics is committed to support our customers worldwide with a 24/7 technical Help Desk.

Help Desk — Contact our technical Help Desk 24 hours a day / 7 days a week:
877-230-0236

Our Infosec support page is designed to make it easy for customers to access the information they need. Please visit www.gdmissionsystems.com/infosecsupport for the following support features:

  • Product Update Notifications — Sign up to receive technical bulletins, upgrade notices and other important product information automatically via E-mail
  • Warranty Status — Enter the serial number of your encryption device to find out the date your warranty or maintenance expires
  • Depot Status— Track your encryptor through the depot
  • Order Status— Track the status of your orders
  • Software Requests — Request Software Upgrades for your TACLANE encryptors, GEM Patches and GEM Lite Software

NSA IDIQ MIPR Blackout Date Information

In support of the National Security Agency (NSA) and their customers during the Agency’s procurement blackout period of July 3rd 2019 to September 30th 2019 for MIPRs and August 6th 2019 to September 30th 2019 for e-MIPRs, General Dynamics Mission Systems will accept direct purchases from Government customers and end users via either purchase order or credit card for all supplies and services offered on the NSA IDIQ Contract.

Literature

  • Click here to download the TACLANE-Nano Datasheet [PDF]
  • Click here to request any of our TACLANE Whitepapers
  •  Image of a forward-deployed solider

    TACLANE Agile Performance Enhancing Proxy (PEP) Whitepaper

    The TACLANE Agile Performance Enhancing Proxy (PEP) function works by hosting a specialized version of TCP resulting in better performance than an end-to-end standard TCP. Request our whitepaper to learn more about how this software feature increases network availability and performance over disadvantaged networks.

     RUZ Whitepaper Cover Thumbnail

    TACLANE Render Useless Zeroize (RUZ) Whitepaper

    The new TACLANE RUZ feature is ideal for unattended operations and other high risk, hostile environments that are susceptible to overrun or unplanned leave behind. Request this whitepaper to learn how this feature reduces personnel risks, saves costs associated with equipment and logistics so Operators can focus on mission priorities.

Pricing

  • For Pricing and Information on How to Order call 888-897-3148 or email infosec@gd-ms.com

TACLANE-Nano Product News


General Dynamics and Cubic Mission Solutions Integrate Products to Bring Encrypted Communications to Tactical Environments

May 21, 2019

General Dynamics Mission Systems announces plans to integrate its TACLANE-Nano Type 1 encryptor with Cubic Mission Solutions' DTECH M3X network module stack. The small size of the TACLANE-Nano allows it to plug into the industry's lowest Size, Weight and Power (SWaP) portable network stack, extending operational capability in harsh environments.




General Dynamics Demonstrates New TACLANE-Nano Type-1 Mobile Encryptor for Secure Voice, Video and Data On-the-Move

October 31, 2018

General Dynamics has announced the expansion of its TACLANE portfolio, the world's most widely deployed family of Type 1 encryptors, with the new, small form-factor mobile encryptor, the TACLANE-Nano (KG-175N). The new encryptor was shown operating this year, passing live traffic including real-time streaming video with other TACLANE HAIPE encryptors.
