TACLANE-1G (KG-175G) Encryptor

The First Cyber Defense-Capable HAIPE® at Gigabit Speeds - Now Advanced Cryptographic Capabilities (ACC) Compliant

Networks today carry more traffic, are connected to more devices and are under siege from cyber attacks more than even before. In response to these evolving cybersecurity threats, General Dynamics has developed the TACLANE®-1G (KG-175G). The TACLANE-1G is a smaller, more power efficient 1 Gb/s high-speed and Cyber-Defense capable network encryptor. The TACLANE-1G is ruggedized for both tactical and strategic environments and NSA certified to protect information classified Top Secret SCI and below. The TACLANE-1G is Agile VLAN-capable and can accept TACLANE Trusted Sensor Software to improve network sensing capabilities.

New R4.3 software upgrade provides modernized cryptographic algorithms to defend against advanced cyber threats and Key Management Infrastructure (KMI) Over-the-Network Keying (OTNK) support for faster, simpler and safer operations.



Animated graphic depicting TACLANE-Nano

Secure Mobile Communications at the Tactical Edge

Introducing TACLANE®-Nano: The Smallest, Lightest Certified HAIPE® for Secure Tactical Communications

TACLANE-Nano is the new small form factor addition to the TACLANE family of HAIPE encryptors. Offering 100 Mb/s full-duplex throughput and power options, the TACLANE-Nano provides end-to-end secure voice, video and data in mobile environments.

LEARN MORE

TACLANE FLEX Infographic Gif

The Next-Gen Crypto Modernization Solution is Here!

It's Time to Transition to TACLANE®-FLEX, the Smallest, Lightest, Most Efficient 1 Gb/s Full-Duplex HAIPE

TACLANE-FLEX is the next generation product in a TRUSTED encryption portfolio. Designed for EFFICIENT performance and SWAP-C, the FLEX is SCALABLE to support tomorrow’s mission requirements and ENHANCED with advanced security and user features.

LEARN MORE

Features

  • NSA certified to protect information classified Top Secret and below
  • Increased processing speeds from the core to the edge of your network
  • Simultaneous HAIPE v4.2.5 certified and IPMEIR 1.0 compliant
  • Simultaneous Suite A/B without user intervention
  • 1 Gb/s full-duplex throughput
  • Ruggedized for both tactical and strategic environments
  • Low latency
  • Agile VLAN capable to support load balancing and redundant fail over
  • TACLANE Trusted Sensor software supports trusted packet sensing and reporting
  • Low size, weight and power (SWaP)
  • Suite B IPMEIR providing interoperability with commercial encryptors
  • Interoperable with all HAIPE versions
  • GEM One remote management
  • Familiar TACLANE user interface
  • Rack mountable (2 across in standard 19” rack)
  • Field tamper recoverable
  • Trade-in program available (see "Literature & Pricing" tab)
  • Advanced Cryptographic Capabilities (ACC) Compliant
  • KMI Over-the-Network Keying (OTNK)
  • NEW! TACLANE Universal Rack Mount Shelf Kit - specifically designed, tested, and validated for use with TACLANE-1G

Optional Feature Enhancements

Agile VLAN Software- Enables use of HAIPE security features on Layer 2 VLAN / Non-IP Ethernet traffic while simultaneously supporting standard HAIPE encryption of IP traffic. Benefits include:

  • Elimination of GRE tunnels
  • Bandwidth efficiency
  • Redundancy
  • Load balancing

TACLANE Trusted Sensor (TTS) Software - As cyber attacks become more sophisticated and frequent, addtional security services are required to protect and defend networks and information. The TACLANE Trusted Sensor Software provides this additional security by adding intrusion detection and intrusion prevention capabilities to the TACLANE encryptor. With this new software, all IP packets are inspected for malicious data using Deep Packet Inspection (DPI) and alerts are generated upon signature match. In addition to inspection, the TACLANE Trusted Sensor Software provides netflow and traffic pattern statistics. These additional features aid network administrators in understanding the overall health of the system, enables them to fine tune their filtering and reaction to attacks, as well as provides greater Defense-in-Depth in a cost effective manner. In addition TACLANE encryptors enabled with TACLANE Trusted Sensor Software can be used as a HAIPE encryptor with sensing or in a "sensor only" mode. A key benefit of adding sensing capabilities to the TACLANE is that rules sets - both open source and government classified - can be utilized. TACLANE Trusted Sensor Software is NSA approved and available for purchase today for the TACLANE-1G.

TACLANE and GEM One are trademarks of General Dynamics. HAIPE is a registered trademark of the National Security Agency. All other product and service names are the property of their respective owners.

Specifications

TACLANE-1G Encryptor Data Sheet View Document
Size 1.71” (1U) H x 8.6” W x 12.5” D 19”
Rack Mountable, 2 Across, 1U
< 8 lbs
Power < 40 Watts
Lithium 3.6V for extreme environments
User-replaceable battery
Standard Alkaline AA battery for benign environments
Passively cooled via natural convection
MIL-STD 461E EMI-compliant power supply included
Performance 2 Gb/s IP Throughput (Aggregate)
Supports Jumbo Packets
Supports 4096, duplex SAs
Supports 16,000, Remote Networks/Hosts
Environmental MIL-STD-810G
Operating temp: -40°C to +52°C (-40°F to 126°F)
Storage temp: -40°C to +71°C (-40°F to 160°F)
95% humidity (non-condensing)
MIL-STD 810 (shock, vibration, sand/dust, rain, altitude)
MIL-STD 167-1 (vibration)
MIL-STD 901D (Navy hammer shock)
MIL-STD 461E (electromagnetic compatibility)
Altitude Storage/transit:1,500 ft, below sea level to 60,000 ft above sea level
Operational: 1,500 ft below sea level to 50,000 ft above sea level
EMI / TEMPEST In accordance with NSTISSAM TEMPEST/1-92 Level 1
Reliability 250,000 Hrs Mean Time Between Failure (MTBF)
Interfaces PT and CT Data Ports:
10/100/1000 Base-T (RJ-45) auto negotiation
1000 Base-SX (LC) Standard KG-175GM (Multi-Mode optics)
1000 Base-LX (LC) Optional KG-175GS (Single Mode optics, Intermediate Range)
Console:
10/100 Base-T (RJ-45) auto negotiation
Standard DS-101 Key Fill Port
Key Fill Bus Capability*
Primary Power 12VDC
Remote zeroize input
Standards Compliance

HAIPE v4.2.5
IPMEIR v1.0
HAIPE VLAN
ACC and KMI OTNK

Keying Supports HAIPE to HAIPE Keying, APPK/ PPK, FIREFLY, Enhanced FIREFLY, Internet Key Exchange (IKE) v1/v2, Unclassified/Classified Device Generated Shared Key (DGSK), ACC, OTNK (KMI enabled)

24/7 Customer Support

You are never alone when you partner with General Dynamics to secure your critical information. With the largest deployed base of NSA-certified encryptors worldwide, General Dynamics is committed to support our customers worldwide with a 24/7 technical Help Desk.

Help Desk — Contact our technical Help Desk 24 hours a day / 7 days a week:
877-230-0236

Our Infosec support page is designed to make it easy for customers to access the information they need. Please visit www.gdmissionsystems.com/infosecsupport for the following support features:

  • Product Update Notifications — Sign up to receive newsletters and product update information via E-mail
  • Warranty Status — Enter the serial number of your encryption device to find out the date your warranty or maintenance expires
  • Depot Status— Track your encryptor through the depot
  • Order Status— Track the status of your orders
  • Software Requests — TACLANE encryptors are Field Software Upgradeable locally, via GEM One or the TACLANE Configuration Tool (TCT). To request software upgrades for TACLANE, GEM One software or Computer Based Tutorials (CBTs), use this link.

TACLANE Encryptor Training

The TACLANE Encryptor Operator Training course is a four-day course offered in both our Scottsdale, AZ and Annapolis Junction, MD facilities. The course combines classroom presentations and hands-on-exercises designed to teach you how to install, configure and maintain the TACLANE-FLEX (KG-175F), TACLANE-Nano (KG-175N), TACLANE-Micro (KG-175D), TACLANE-1G (KG-175G) and TACLANE-10G (KG-175X) encryptors in a practical operational environment. The course also includes a complete module of training of our GEM® One encryptor manager software. Students who pass the short written and practical exam at the end of the course will receive a certificate.

Click Here To Learn More

TACLANE Trusted Sensor Software Training

The TACLANE Trusted Sensor Software Training course is a one-day course offered at our Annapolis Junction, MD and Scottsdale, AZ facilities. This hands-on course provides in-depth knowledge and training needed to activate, configure and maintain the TACLANE Trusted Sensor Software to identify and mitigate network intrusions. Topics covered include cybersecurity principles, rule generation, alert configuration, and modes of operation. Students who pass the short written and practical exam at the end of the course will receive a certificate.

Click Here To Learn More

Register Today - Complete our online registration form.

Literature

News

Click here to read the latest news on our Cyber defense products.

Pricing

To see our TACLANE-1G pricing list, please contact us.

It is important for users to ensure their TACLANE-based security solutions are integrated and used with approved ancillary equipment to comply with mission requirements. By using ancillary equipment that has been tested and validated by General Dynamics for use with TACLANE devices reduces risks associated with interoperability, redundancy, environmental factors and even warranty coverage. Please refer to the TACLANE Approved Products List (APL) for a complete list of tested and approved ancillary items available for purchase and supported by General Dynamics. If you have a requirement for an item that is not listed, please contact us.



DOWNLOAD THE TACLANE APL Catalog





TACLANE Approved Products

TACLANE Universal Rack Shelf Kit

TACLANE Universal Rack Mount Shelf Kit
Standard 19” rack mount shelf includes adjustable ears for full extension of up to 24”-30”D and includes hardware to securely hard-mount a combination of TACLANE products including power supplies.


P/N: TLUR-KIT

 TACLANE Universal Rack Large Quick Disconnect

TACLANE Universal Rack Mount Shelf – Large Quick Disconnect Accessory
Optional tray enables quick, easy mounting of (1) TACLANE-1G (KG-175G) encryptor per tray. Two Large Disconnect Accessory trays can be accommodated on the TACLANE Universal Rack Mount Shelf.


P/N: TLUR-LQD

 TACLANE Universal Rack Power Supply Quick Disconnect

 TACLANE Universal Rack Mount Shelf – Power Supply Quick Disconnect Accessory
Optional tray enables quick, easy mounting of (1) power supply supporting TACLANE-1G (KG-175G)


P/N: LUR-PWQD

TACLANE-1G CIK- TACLANE APL  TACLANE-1G CIK
P/N: 1G-101B
 RJ45 10-100-1000 BaseT Cable - TACLANE-1G - TACLANE APL RJ45 10/100/1000 BaseT Cable
P?N: 1G-105A
Fiber Optic Cable TACLANE1G Single Mode - TACLANE APL  Fiber Optic Cable (TACLANE-1G) (Single Mode)
P/N: 1G-SMC
Fiber Optic Cable TACLANE1G Multi Mode - TACLANE APL  Fiber Optic Cable (TACLANE-1G) (Multi Mode)
P/N: 1G-MMC
AC Power Adapter (TACLANE-1G) - TACLANE APL  AC Power Adapter (TACLANE-1G)
P/N: 1G-PWR



Items can be purchased on IDIQ or directly from General Dynamics Mission Systems. For more information please contact our INFOSEC team at (781) 410-9400, (888) 897-3148 or by filling out our form.

Which TACLANE Is Right For Your Mission?

Certified to protect information classified Top Secret/SCI and below, the TACLANE portfolio extends from ruggedized, small form factor Inline Network Encryptors (INE) to high performance encryption platforms (200 Mb/s to 20 Gb/s aggregate throughput). Compare our TACLANE network encryptors and see which one is best for your mission.

Compare TACLANE Encryptors
