Sectéra BDI Terminal

Cyber and Electronic Warfare Systems - Terminal Left Facing - Image

Secure Voice & Data Communications via Satellite, Phone, Fax and PCs

When high assurance secure communications is required in remote areas where terrestrial communications are not available, the Sectéra^® BDI (Black Digital Inferface) Terminal provides end-to-end voice and data security for digital communications.

Analog or digital encryptor for voice, data, and fax
NSA certified for Top Secret codeword and below
Small, portable, compact and lightweight

The Sectéra Wireline Terminal is currently available for sale in limited quantities. Contact our INFOSEC Team for more details.

Features
Specifications
Literature
Customer Support

Features

Analog or digital encryptor for voice, data, and fax
Secure communications for Iridium®, Inmarsat®, Globalstar and Thuraya satellite phones
NSA certified for Top Secret codeword and below
High quality voice for secure and non-secure calls
Small, portable, compact and lightweight
Non-Type 1 AES version available
Software upgradability allows users to incorporate latest enhancements
Contains security and authentication display and voice prompts to assist with security setup
TSG and TEMPEST approved

Sectéra is a registered trademark of General Dynamics.

Specifications

Sectéra BDI Terminal Data Sheet	View Document
Motorola Iridium Portable Satellite Phones Supported	9500, 9505, 9505A, 9522
Size	5" W x 1.3" H x 4.6" D Weight: 10 oz. Volume: 30 cu in
Black Interfaces	PSTN: RJ11 RS530/RS232: 25 Pin custom
Red Interfaces	Phone: RJ11 RS232: 9 Pin RS232
Modem	V.32/V.34/V.90
Black Analog Data Rates	Up to 56,000 BPS*
Black Digital Data Rates	Up to 128 KB/s (depending on underlying network)
Secure Dial	Transmit/Receive: Yes
Speech Processing	Toll Quality: 6.4 KBPS — G.729D 2400 BPS — MELP
Power	AC Power: 110 to 220 VAC DC Power: 9 VDC +/- 5% (< 6 Watts) (supplied by battery pack)
Environment	Tested for Thermal Shock, Vibration, Shock and Temperature Operational: 0° C to 50° C (32° F to 122° F) Storage: -20° C to 70° C (-4° F to 158° F)
Approvals	TSG and TEMPEST Approved Connection (Telecom): ANSI/TIA-968-A-2002 (US) CTR21 (EU) IS CS-03, Issue 8 (Can) AS/ACIF S002:2001 (AUS) PTC200: ISS2 (NZ) Safety: UL 60950, EN60950, IEC60950 EMI/EMC: FCC Part 15 subpart B, Class B EN55022/EN55024

Literature

Sectéra BDI Terminal Datasheet [PDF]
For Pricing and Information on How to Order call 888-897-3148 or email infosec@gd-ms.com.

24/7 Customer Support

You are never alone when you partner with General Dynamics to secure your critical information. With over 100,000 deployed NSA-certified encryptors worldwide, General Dynamics is committed to support our customers worldwide with a 24/7 technical Help Desk.

Help Desk — Contact our technical Help Desk 24 hours a day/7 days a week:
877-230-0236

Our Infosec support page is designed to make it easy for customers to access the information they need. Please visit www.gdmissionsystems.com/infosecsupport for the following support features:

Product Update Notifications — Sign up to receive technical bulletins, upgrade notices and other important product information automatically via E-mail
Warranty Status — Enter the serial number of your encryption device to find out the date your warranty or maintenance expires
Depot Status— Track your encryptor through the depot
Order Status— Track the status of your orders
Software Requests — Request Software Upgrades for your TACLANE encryptors, GEM Patches and GEM Lite Software
