Sentinel M-Code GPS Receiver

Accurate military code certified positioning service in space

General Dynamics’ Sentinel M-Code GPS Receiver provides Precise Positioning Service position, velocity, and time information for Low Earth Orbit (LEO) and Geostationary Earth Orbit (GEO) applications. MEO and HEO orbits are also available. Performance and satellite visibility are enhanced through the use of dual antennas; each of the 64 GPS channels can be assigned to either antenna.

  • Design Based on Legacy Monarch™ GPS Receiver Space-Qualified Digital Design
  • 1,000+ Equivalent Years of Accumulated Trouble-Free DoD Space Heritage; > 6M Orbits
  • Same Reliable Position, Velocity, Time, Pseudorange and Carrier Phase @ 10 Sec Optional
  • Features


    • Optional Relative Navigation Position, Velocity, and Time Modes
    • RS-422 I/O interface and control, protocol similar to our Legacy Viceroy® C/A Receiver
    • Optional MIL-STD-1553B Interface & Control, protocol similar to our legacy Monarch-M P(Y) code receiver
    • LEO, GEO capable with MEO and HEO option
    • GEO Sidelobe Acquisition and Tracking Algorithms enable continuous PNT availability
    • Fast Acquisition Processor enables rapid COLD start capability
    • Integrated Anti-Jam Technology and anti-spoof algorithms enable superior performance in GPS contested and denied environments.
    • 64 Channels, L1 and L2 Capable
    • C/A, P(Y) and Modernized M-Code, with optional L2C civil signal
    • Provides Near Real-time Position, Velocity and Time Measurements for Superior User Performance
    • Relative Navigation Capability Allows for Differential Position, Velocity and Time Determination Between Co-orbiting Spacecraft (Optional)
    • Precision Time Stamping Allows Unprecedented Accuracies in Space
    • Precise Position Service Key Management Supports All Selective Availability Anti-spoof Module (SAASM) Unique Keying
    • Single or Dual Antenna Capability Allows the Spacecraft User Installation Flexibility and Performance
    • Qualified and Tested for the Space Environment: Pyrotechnic Shock, Random Vibration, Thermal-vacuum and EMI/EMC (Tailored Mil-Std-461F)
  • Specifications


    Sentinel M-Code GPS Receiver Data Sheet

    View Document

    Receiver Architecture

    64 Channels PPS-GPS C/A, P(Y), M-Code Channels, L2C available as an option
    Dual Antenna – any channel to either antenna
    Frequencies & Codes: L1 & L2, C/A Code, P(Y), M-Code, L2C optional
    Narrow Bandwidth Acceleration-Aided Carrier/Code Tracking
    Tracking, and Navigation Algorithms based on Monarch-M™ GPS Receiver
    Kalman Filter-based navigation solution with integrated high fidelity orbit propagator bridges gaps between GPS outages
    On-Orbit Software Reprogrammable

    Input / Output RS-422, Follows Legacy Viceroy™ Receiver ICD (Optional: MIL-STD-1553B, Follows Legacy Monarch™ / Monarch-M™ ICD)
    One Pulse per Second (GPS, UTC, or Measurement Epoch Time)
    Time Stamp Input Signal, measures the time of an external pulse
    LEO Solution Accuracy Autonomous Position: 4.0 meters, 1 sigma, < 1 meter typical
    Autonomous Velocity: < 2 cm/sec, 1 sigma, < 0.5 cm/sec typical
    Clock and 1PPS Absolute: < 50 ns 1 sigma, < 5 ns typical
    Time Strobe Input: < 50 ns, 1 sigma
    Optional Relative PVT Mode: 0.5m, 0.5 cm/sec, 4 ns (1 sigma)
    GEO Solution Accuracy Autonomous Position: 25 meters, 1 sigma, < 5 meter typical
    Autonomous Velocity: < 2 cm/sec, 1 sigma, < 0.5 cm/sec typical
    Clock and 1PPS Absolute: < 50 ns 1 sigma, < 5 ns typical
    Time Strobe Input: < 50 ns, 1 sigma
    Cold Start Time to First Fix (self-test complete & assumed keyed) LEO < 10 minutes, 67% probability, 4 min typical
    GEO < 15 minutes, 90% probability, 8 min typical
    Orbital Dynamics Altitude: LEO, GEO (200 km – 45,000 km), MEO & HEO Optional
    Velocity: up to 16,000 meters/second
    Acceleration: 1G
    Optional and Custom Features External Reference Oscillator or Internal Precision
    GEO Sidelobe Acquisition and Tracking Software
    High Dynamics Acquisition & Tracking
    Physical/Environmental Radiation: 100 Krads
    Single Event Upset: < 1 per year
    Single Event Latchup: Immune
    Reliability: 0.90, 10 year, 30°C Baseplate, 100% duty cycle
    Vibration: 16.6 Grms
    Pyro Shock: 2000 G
    Temperature: -34°C to +71°C
    Size: 180 x 160 x 60 mm-Envelope
    Weight: < 2.5 kg
    DC Power: < 9 w typical LEO (dual antenna), < 8 w typical GEO (single antenna)
