RCP-2000 ModuMAX/QuadMod Remote Control Panel

RCP-2000

The RCP-2000 allows you to easily monitor and control any ModuMAX or QuadMod solid-state power amplifier (SSPA) or other compatible SSPA from a remote location. The RCP-2000 enables the remote, real-time operation of a single SSPA, which is especially convenient for installations where the SSPA is located in an inaccessible or inconvenient location.



Features

  • Duplicates menus and functions available at SSPA front panel
  • Provides customer Serial I/O port (up to 28.8 kBps)
  • Audible alarm
  • Worldwide AC input capability
  • Can be located up to 1.3 km (4000') from SSPA with inexpensive cable
  • Compatible with all ModuMAX or QuadMod SSPAs with firmware version 1.0x or higher

Specifications

Parameter

Notes

Min.

Nom./Typ.+

Max.

Units

Power Requirements Voltage, Standard 85
265 Vac

Frequency
47   63 Hz

Power
13.5 W

Voltage, Option 5
20   32 Vdc

Voltage, Option 6
42
56 Vdc
Operating Temperature Range
  0   +50 °C
SSPA Link Cable Length
4000 (1.3) ft (km)
Size
  19 W x 1.72 H x 17.52 D
482.6 x 43.7 x 445

inches
mm
